183 ka papaʻaina papa hana

Model:KGS120Z

ʻO Kinggle Kgs120z heʻokiʻokiʻia he 183 mau pale plastic placle e pili ana i nā mīkini i hoʻopaʻaʻia no ka papa inoa o nā papa inoa o nā papa inoa. Ua hoʻokō piha i nā papaʻaina kīwī a iʻole nā koina o nā mīkini kīwaha kīwaha

Volume: 1000lKaumaha: 38T

E hoʻouna i ka nīnau

Hōʻike huahana Specification Application

ʻO Kgs120z 183ʻO ka mīkini hana plastik e hana i ka mīkini hana no ka huahana pā'ālua pā'ālua E like me ka papaʻaina / Ware House Etc. Cloud Blove Bloty Moding mīkini hiki ke kūpono E hui i kēlā mau koi huahana kūikawā kūikawā, me ka wikiwiki kiʻekiʻe hana e hoʻopakele i ke kumukūʻai o ka waihona.
Komo i ka moog 100 corronler controller, robot lima, a lalo BUGS GRANSTALLS, hoʻonui i ka huahana a me ka maikaʻi.

Nā hiʻohiʻona a me nā pono

Hoʻohana no nā huahana hana i nāʻoihana likeʻole. Inā he nui nā mea e pili ana i nā corosion-resistant i kaʻoihana kemika, nā pahu e hoʻopili ana i nāʻoihana
ʻO ke kaʻina hana e hoʻonui ai i kaʻenehana cute-cecter-cecter a me ka manaʻo e pili ana i nā hiʻohiʻona kiʻekiʻe o ka mīkini mua o 120z. E hoʻoponopono pololei i ka huina o ka kahe a me ka hāʻawiʻana i nā waiwai e maopopo ai ka nui o ka nui o ka huahana, a hoʻopau i ka ikaika o keʻano he nui e hānai ana.

Specifications

serial number	Material HDPE…	Mold closing oil cylinder(single cylinder)
serial number	Material HDPE…	Machine model:KGS120Z
Specifications
1	Max container capacity	1000 L
2	Output(dry Cycle)	300 PC/HR
3	Machine Dimension(L×W×H)	8.3 M ×3.4 M × 6.8 M
4	Machine weight	38 T
Clamping Unit
1	Clamping force	1200 KN
2	Mold platen size(W×H)	1300 MM×1900 MM
3	Platen openingstroke	600 MM-1600 MM
4	Platen moving stroke	700 MM
5	Max mold size(W×H)	1000 MM×2000 MM
6	Mold thickness	630 MM - 830 MM
Power
1	Servooil pump motor power	25 KW
2	Servo pump displacement	200 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	2 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	120 L/min
7	Average energy consumption	110 KW -130 KW
Extruder unit
1	Screw diameter	120 MM
2	Screw L/D ratio	30 L/D
3	Melting capacit for HDPE	350 Kg/hr
4	Number of heating zone	6 ZONE
5	Screw heating power	32.5 KW
6	Screw fanpower	0.6 KW
7	Extruder motor power	90 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	38.8 KW
3	Maxdie-pin diameter	700(800) MM
4	Accumulator capacity	25(30) L
5	(PE)Accumulator weight	18(22) KG
