ʻO ka mīkini kīwīʻo 5l

Model:KGB5L

ʻIke i ka maʻalahi a me ka maikaʻi o kā mākou wahi paʻa paʻa paʻa mau. Hoʻolālāʻia no ka poʻe 5l nā mea e pono ai keʻano he 5l st i nā mea i kohoʻia, e hui pū me kāu mau hana i hoʻolaʻaʻia.

VIMume: 5LKaumaha: 3.0T

E hoʻouna i ka nīnau

Hōʻike huahana Specification Application

Inā makemakeʻoe i kahi mea i hoʻolaʻaʻiaʻo 5L ma kahi o ka papa inoa o ka mīkini uila E hoʻokaʻaʻike mai iā mākou i kēia lā eʻimi i ko mākou kumukūʻai hoʻokūkū aʻike i keʻano o kēia mīkini ke hoʻonui i kāu mau hana hana.

Nā hiʻohiʻona a me nā pono

● Hoʻokahi kikowaena kikowaena kikowaena kikowaena kikowaenaʻana i ka mechannism, pono me ka pākēlī a me ka mea e hōʻoia ai i nā hana e hoʻololi ai i nā hana.
● Ua hoʻolālāʻia ke poʻo make me kahi'ōnaehana e hānai ana i ka'ōnaehanaʻana, e hoʻohālikelike ana i ka hoʻoiliʻana i ka waiwai o ka huahana.
● Hoʻopiliʻia ka'ōnaehana uila uila holomua e Mitsubishi Plc, a hele mai me nā pihi manuahi manuahi, eʻae ana i nā mea hana wikiwiki a hoʻoponopono i ka maʻalahi.
● Me ka nui o ka helu helu helu nui o 5l, e kū ana e like me ke koho kiʻekiʻe no ka hana haʻahaʻa haʻahaʻa no 2l a 5l.
● Ma nā'ōlelo a nā huahana huahana, hāʻawi i nā koho Veditarity e pili ana i hoʻokahi,ʻelua mau mea hana e pili ana i nā mea kūʻai aku.
● Hōʻike ka'ōnaehana hydraulic i kahi hoʻolālā'ē aʻe, e hāʻawi ana i nā wikiwiki kiʻekiʻe a me nā wikiwiki wikiwiki.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB5L
Specification
1	Max container capacity	5L
2	Output(dry Cycle)	500 PC/HR
3	Machine Dimension(L×W×H)	3.1M x2.2 M x2.5 M
4	Machine weight	3.0 T
Clamping Unit
1	Clamping force	65 KN
2	Mold platen size(W×H)	368 MM x 450 MM
3	Platen openingstroke	188 MM -538 MM
4	Platen moving stroke	420 MM
5	Max mold size(W×H)	410 MM×450 MM
6	Mold thickness	200 MM - 310 MM
Power
1	Servooil pump motor power	15KW
2	Servo pump displacement	100 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	0.6 M²/MIN
5	Cooling water pressure	0.2-0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	16 KW-25 KW
Extruder unit
1	Screw diameter	60 MM
2	Screw L/D ratio	25 L/D
3	Melting capacit for HDPE	55 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.25 KW
7	Extruder motor power	15 KW
Die head
1	Number of heating sections	3*8 ZONE
2	Heating power	3.7 KW
3	Maxdie-pin diameter	150 MM
4	2Center distance of double die head	150-180MM
5	2MTMax die-pindiameter	80MM

Hōʻailona Wela: ʻO ka mīkini kīwīʻo 5l
